| Printing method |
Direct thermal printing |
| Dot density |
384 dots/line (203×203 DPI) |
| Print speed |
100 mm/s |
| Effective printing width |
48 mm
TF50KS-E
Thermal paper Model AF50KS-E
Width: 57.5 ± 0.5 mm
Weight: 53 ~ 80 g/m2 |
| Paper specification |
Outer diameter: Φ83 mm (Max.)
Thickness: 0.065 ~ 0.15 mm
Note: The inner diameter of paper shaft is Φ12mm and the outer diameter of paper shaft is Φ18mm. |
| Character set |
ASCII: 13 international character sets |
| Line spacing |
30/203 inch, or programmable in 1/203 inch increment |
| Interface |
This printer can be equipped with the following interfaces:
Parallel interface: Centronics
USB interface: 2.0 Full-Speed
USB interface (2.0 Full-Speed) + Serial interface [RS-232C (DB9)]
USB interface (2.0 Full-Speed) + Ethernet interface (10/100Base-T)
USB interface (2.0 Full-Speed) + Serial interface [RS-232C (DB9)] + Ethernet
interface (10/100Base-T)
USB interface (micro) + Bluetooth
USB interface (micro) + Wi-Fi (802.11b/g/n)
Wi-Fi (802.11b/g/n)
Note: 1. Only one of the data interfaces is supplied when leaving the factory. 2. Please take the specific interface as standard. |
| Cash drawer interface |
RJ-11, 12V (DC)/1A |
| Special function |
Online parameter settings, Software online update |
| Input buffer |
4 KB
ESC/POS Emulation |
| Control command |
Character printing command: Support ANK characters, user-defined characters and Chinese characters 1-2 times enlarged printing, can adjust character line spacing
Dot image printing command: Support different densities dot images and downloading image printing
Linear bar code: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, CODE128, ITF-25, CODABAR |
| Power supply (AC adapter) |
IN Input voltage: 100 ~ 240 V(AC)
Frequency: 50Hz ~ 60Hz
OUT Output voltage: 8.5 V(DC)
Current: 3 A |
| Power input |
Parameters Input voltage: 8.5 V(DC)
Current: 3 A
Warning: Please use the original AC adapter only. Manufacturers have no responsibilities for the problems which are led by using unauthorized AC adapter.
Temperature: 5 ~ 35℃ |
| Environmental conditions |
Operating environment Humidity: 25~ 80%RH (No condensation)
Temperature: -40 ~ 55℃
Storage environment Humidity: ≤93%RH (40℃, No condensation) |
| Weight |
Approx.1 Kg |
| Noise |
＜38 dB (A) (ISO7779 standard) |
| Physical dimensions |
120 mm (Width) × 192 mm (Depth) × 130 mm (Height) |
| Power consumption |
① Operating: 27 W; ②Standby: Approximately 1.3 W Note: Only when the product is unconnected with outer power supply, can it achieve zero energy consumption state. |
| Dot spacing |
Vertical: 0.125 mm
Horizontal: 0.125 mm |
| ASCII dot matrix |
12 (width) × 24 (height)
9 (width) × 17 (height) |
| ASCII size |
1.50 (width) × 3.00 (height) mm |
| Chinese dot matrix |
24×24 |
| Chinese size |
3.00 (width) × 3.00 (height) mm |
| Characters per line |
ASCII 32 (12×24 dot matrix) |
| Paper feed mode |
Unidirectional feed with friction |
| Code page |
76 kinds |
| Paper cut |
Cut manually Note: Without auto-cutter |
| Control panel |
1 button and 3 LED indicators |
